Products

We are leading Dealer located in Coimbatore involved in offering superior Quality various types of Air Compressors: GA550-25L GAHL Oil Free Air Compressor Brand: GAHL Model:GA550-25L Power: 0.55KW/0.75HP Voltage: 240V/50Hz Exhaust Volume: 110L/Min / 3.9 CFM Maximum Working Pressure: 8 Bar Noise ≤60dB Tank Capacity: 25L Product Warranty: one year against

The 90 – 132 kW range of lubricated screw compressors comprises of fixed speed and regulated speed (RS) models. Ingersoll Rand has unveiled its newest oil-lubricated compressors for its leading CompAir L-Series range, offering best-in-class efficiency. The compressors are equipped with a premium high efficiency electric motor, which can be upgraded to an ultra efficient energy saving IE4 electric motor. The RS (regulated speed) efficiently handles the varying air demand found in most plant air systems. The compressors incorporate quality components, such as high performance separator filter, large surface after cooler and thermostatically controlled motor driven fan. The design concept is not only based on energy efficiency but also on high availability and low maintenance costs. Therefore these packages ensure all service points are easily accessible. The reduced number of moving parts contributes to lower maintenance costs additionally. High reliability and high quality compressed air Comprehensive and user-friendly touch-screen compressor controller Superior energy efficiency High flexibility Small footprint Excellent accessibility contributing to the low maintenance costs Innovative oil regulation valve improves efficiency up to 5% (depending on model)

The 55 – 75 kW range of lubricated screw compressors comprises of fixed speed and regulated speed (RS) models. The new compressors deliver efficiency improvements of up to 8 per cent when compared with previous models, plus a 5 per cent higher flow rate. The new compressors are available in both fixed and regulated speeds – which can help reduce a system’s total cost of ownership significantly – as well as air-cooled and water-cooled options. Pressure range: 5 to 13 bar Volume flow: 2.1 to 14.03 m³/min Motor power: 55 to 75 kW

The new versatile screw compressor range from 30 to 45 kW can be configured to meet the customers’ efficiency requirements. The E-models feature a larger air end delivering highest efficiency levels. Well known in the industry for quality and reliability, CompAir continuously develops the L-Series achieving cutting edge performance and efficiency. The regulated speed models save energy by matching the output to the plant air demand. All fixed speed models are available with integrated dryer option. The E-Models of the L-Series screw compressors feature an extra large airend with optimised rotor tip speed achieving up to 6% energy savings. The largest cost component of a compressor is the energy to run it. The reduction of energy costs significantly impacts on the total costs of ownership. The additional investment costs for this range of super efficient compressors will pay back in many cases in less than 12 months. The extra large air end also has a longer life expectancy. Real Time Clock – allows pre-setting of compressor starting/stopping Second Pressure Setting Integrated Cooling and Dryer Control Fault History Log – for in-depth analysis Remote Control via Programmable Inputs Auto Restart after Power Failure Optional Base Load Sequencing SD Card – stores several run characteristics

Energy efficiency was the key focus of the development of this recent compressor range. The high-output in-house made airend with slow rotational speed reduces significantly the energy costs. In addition to this, the innovative design of the fail safe shaft seal, integrated oil filter and oil regulation valve, ensures external hoses are reduced to a minimum to guarantee the highest levels of quality and reliability are achieved. This range comprises of fixed speed and regulated speed (RS) models and is available with energy-saving integrated refrigerant dryer and high efficient heat recovery system. High reliability and high quality compressed air Superior energy efficiency High flexibility Small footprint Low maintenance costs

The design concept is based on absolute reliability and flexibility. This range incorporates the latest technological advances and components which are designed for long service life to offer operators total piece of mind. The availability of a wide range of different version and options makes them suitable for almost all applications. This ranges from additional regulated speed models, receiver mounted versions including refrigerant dryer (Airstation) and integrated heat recovery option. High reliability and high quality compressed air Easy operation and easy installation High flexibility Small footprint Energy efficient fully integrated air end design Low maintenance costs

A Scroll Compressor is also referred to as a Spiral Compressor, a scroll pump or a scroll vacuum pump. The Rotary Spiral Scroll design creates a continual compressed airflow over multiple stages and there is no need for oil lubrication. A scroll compressed air system runs quieter and more smoothly than a reciprocating version because there are only two moving parts – a fixed scroll and an orbital scroll. Fewer parts make the scroll compressor energy-efficient, highly reliable, and less prone to mechanical failure. Compared with a rotary screw compressor, a scroll compressor vibrates less and is almost noiseless. Scroll compression An orbiting (rotating) scroll and fixed scroll housing are mated to create the compression chambers. The continual movement of the orbiting scroll moves atmospheric air from the intake toward the center, compressing the air into progressively smaller areas. The compressed air is directed to the center discharge port of the compressor. Discharge pressure is accomplished during multiple stages of compression, resulting in a continuous intake suction and discharge. High reliability and high quality compressed air Easy operation and easy installation High flexibility Small footprint Energy efficient fully integrated airend design Low maintenance costs

L02 – L06, Flow: 0.18 to 0.89 m³/min, 10 bar low-noise compressors, receiver mounted with refrigerant dryer options available. To meet the requirements of the individual customer demands the range of compressors can be combined with numerous options to provide everything from a stand alone compressor, receiver mounted or complete Airstation including refrigerant dryer. Compressor Brand CompAir Weight 151Kg-179kg|242kg-339Kg|261kg-364kg Full Features Base Mounted| Receiver Mounted| Airstation Model No CompAir L02 – L06 Motor Rating 2.2/3/4/5.5/7.5 HP Free Air Delivered 6.3 cfm to 31.5 cfm Noise Level 70 DB(A)

AIR PREPARATION UNITS Model PHI-FRL Components FR,FRL Port Size Rc1/4 Rc3/8 Rc1/2 Medium Air Operating pressure range 01 MPa Proof pressure 1.5Mpa Regulated pressure range 0.05 0.85MPa Ambient temperature -5 - +60??C (No freezing) Filter element Standard: 5m Option: 40m Lubricating oil capacity 65 c.c Min. Flow for oil drop 50 l/min 60 l/min Recommended lubricating oil Turbine oil ISO-VG32 Attachment Pressure gauge (PG-20), T-type bracket Weight 845 g

Technical specification Suitable fluid: compressed air Working pressure: Series standard with polycarbonate bowl (standard ) : 0.5 to 12 bar. Series standard with anti alkali & acid bowl (optionnal ) : 0.5 to 15 bar. Series standard with aluminium bowl (optionnal): 0.5 to 16 bar. Working temperature: - 10° to + 60°C Constituent materials: - body: aluminium die-cast (series mini: polycarbonate) Thread type: BSP parallel

PNEUDRI MXLE Large Flow Air Dryer Large flow low energy modular compressed air dryers providing pressure dew points of -70°C and -40°C with flow rates up to 2040 m³/hr @ 7 barg, even greater flow rates can be achieved by multi-banking the dryers.

PNEUDRI MX SeriesLarge flow modular compressed air dryers providing pressure dew points of -70°C and -40°C with flow rates up to 2040 m³/hr @ 7 barg, even greater flow rates can be achieved by multi-banking the dryers.
